Data Structures |
| class | nxyter::NxI2c |
| | Represents the I2C interface of an nXYTER. More...
|
Namespaces |
| namespace | nxyter |
| | namespace to hold nXYTER specific classes
|
Enumerations |
| enum | nxyter::nxRegs {
nxyter::kNxRegMask00 = 0,
nxyter::kNxRegMask01 = 1,
nxyter::kNxRegMask02 = 2,
nxyter::kNxRegMask03 = 3,
nxyter::kNxRegMask04 = 4,
nxyter::kNxRegMask05 = 5,
nxyter::kNxRegMask06 = 6,
nxyter::kNxRegMask07 = 7,
nxyter::kNxRegMask08 = 8,
nxyter::kNxRegMask09 = 9,
nxyter::kNxRegMask10 = 10,
nxyter::kNxRegMask11 = 11,
nxyter::kNxRegMask12 = 12,
nxyter::kNxRegMask13 = 13,
nxyter::kNxRegMask14 = 14,
nxyter::kNxRegMask15 = 15,
nxyter::kNxRegVcg = 16,
nxyter::kNxRegIcgfoll = 17,
nxyter::kNxRegVth = 18,
nxyter::kNxRegVbfb = 19,
nxyter::kNxRegVbiasF = 20,
nxyter::kNxRegVbiasS = 21,
nxyter::kNxRegVbiasS2 = 22,
nxyter::kNxRegVcm = 23,
nxyter::kNxRegcal = 24,
nxyter::kNxRegiCOMP = 25,
nxyter::kNxRegiDUR = 26,
nxyter::kNxRegiINV = 27,
nxyter::kNxRegiPDH = 28,
nxyter::kNxRegiTWC = 29,
nxyter::kNxRegSpare30 = 30,
nxyter::kNxRegSpare31 = 31,
nxyter::kNxRegConfig0 = 32,
nxyter::kNxRegConfig1 = 33,
nxyter::kNxRegOverflowLSB = 34,
nxyter::kNxRegOverflowMSB = 35,
nxyter::kNxRegMissTokenLSB = 36,
nxyter::kNxRegMissTokenMSB = 37,
nxyter::kNxRegdelayTestPuls = 38,
nxyter::kNxRegdelayTestTrig = 39,
nxyter::kNxRegSpare40 = 40,
nxyter::kNxRegSpare41 = 41,
nxyter::kNxRegTrimDAQPower = 42,
nxyter::kNxRegdelayClock1 = 43,
nxyter::kNxRegdelayClock2 = 44,
nxyter::kNxRegdelayClock3 = 45
} |
| | Names for nXYTER I2C Registers.
More...
|
Variables |
| static const uint8_t | nxyter::kNxC0TestPulsEnable = 1<<0 |
| static const uint8_t | nxyter::kNxC0TestPulsSync = 1<<1 |
| static const uint8_t | nxyter::kNxC0TestPulsPolarity = 1<<2 |
| static const uint8_t | nxyter::kNxC0TestTrigEnable = 1<<3 |
| static const uint8_t | nxyter::kNxC0TestTrigSync = 1<<4 |
| static const uint8_t | nxyter::kNxC0Disable32MHz = 1<<5 |
| static const uint8_t | nxyter::kNxC0Disable128MHz = 1<<6 |
| static const uint8_t | nxyter::kNxC0TsLsbClockSelect = 1<<7 |
| static const uint8_t | nxyter::kNxC1CalibSelectMask = 0x3 |
| static const uint8_t | nxyter::kNxC1FrontEndPolarity = 1<<2 |
| static const uint8_t | nxyter::kNxC1ReadClockSelect = 1<<3 |
