(r4864/r4341)
Go to the source code of this file.
Defines | |
| #define | TRB_TDC3_CHANNELS 65 |
| #define | TRB_TDC3_NUMTDC 1 |
| #define | TRB_TDC3_NUMBOARDS 16 |
| #define | SET_TRBS {1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1} |
| #define | TRB_TDC3_COARSEBINS 0x800 |
| flag that indicates that the online monitor should make the TH2 maps | |
| #define | TRB_TDC3_COARSEUNIT 5 |
| #define | TRB_TDC3_EPOCHUNIT (TRB_TDC3_COARSEUNIT * TRB_TDC3_COARSEBINS) |
| #define | TRB_TDC3_FINEBINS 0x400 |
| #define | TRB_TDC3_DELTAHISTBINS (200 * TRB_TDC3_FINEBINS) |
| #define | TRB_TDC3_EPOCHBINS 0x10000000 |
| #define | TRB_TDC3_COARSE_COND_LOW 0 |
| For conditions. | |
| #define | TRB_TDC3_COARSE_COND_HIGH TRB_TDC3_EPOCHUNIT |
| #define | TRB_TDC3_FINE_COND_LOW 0 |
| #define | TRB_TDC3_FINE_COND_HIGH TRB_TDC3_FINEBINS |
| #define | TRB_TDC3_LdeltaT_COND_LOW (-TRB_TDC3_FINEBINS) |
| #define | TRB_TDC3_LdeltaT_COND_HIGH TRB_TDC3_FINEBINS |
| #define | TRB_TDC3_TdeltaT_COND_LOW (-TRB_TDC3_FINEBINS) |
| #define | TRB_TDC3_TdeltaT_COND_HIGH TRB_TDC3_FINEBINS |
| #define | TRB_TDC3_CALIBFREQ 10000 |
| This number defines how often calibration is performed. | |
| #define | TRB_TDC3_CALIBENTRIES 500 |
Define Documentation
| #define SET_TRBS {1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1} |
trb id: 0 1 2 3 4 5 6 7 8 9 A B C D E F | | | | | | | | | | | | | | | |
Definition at line 10 of file TTrbDefines.h.
| #define TRB_TDC3_CALIBENTRIES 500 |
Definition at line 34 of file TTrbDefines.h.
| #define TRB_TDC3_CALIBFREQ 10000 |
This number defines how often calibration is performed.
Definition at line 33 of file TTrbDefines.h.
| #define TRB_TDC3_CHANNELS 65 |
Definition at line 4 of file TTrbDefines.h.
Referenced by TTrbProc::ProcessTDCV3().
| #define TRB_TDC3_COARSE_COND_HIGH TRB_TDC3_EPOCHUNIT |
Definition at line 24 of file TTrbDefines.h.
| #define TRB_TDC3_COARSE_COND_LOW 0 |
For conditions.
Definition at line 23 of file TTrbDefines.h.
| #define TRB_TDC3_COARSEBINS 0x800 |
flag that indicates that the online monitor should make the TH2 maps
Definition at line 15 of file TTrbDefines.h.
Referenced by TTrbProc::TTrbProc().
| #define TRB_TDC3_COARSEUNIT 5 |
Definition at line 16 of file TTrbDefines.h.
Referenced by TTrbProc::DoCalibration(), TTrbProc::EvaluateTDCV3Data(), and TTrbProc::TTrbProc().
| #define TRB_TDC3_DELTAHISTBINS (200 * TRB_TDC3_FINEBINS) |
Definition at line 19 of file TTrbDefines.h.
Referenced by TTrbProc::GenHistos1(), TTrbProc::GenHistos2(), and TTrbProc::GenHistos3().
| #define TRB_TDC3_EPOCHBINS 0x10000000 |
Definition at line 20 of file TTrbDefines.h.
Referenced by TTrbProc::GenHistos1().
| #define TRB_TDC3_EPOCHUNIT (TRB_TDC3_COARSEUNIT * TRB_TDC3_COARSEBINS) |
Definition at line 17 of file TTrbDefines.h.
Referenced by TTrbProc::EvaluateTDCV3Data(), and TTrbProc::GenHistos1().
| #define TRB_TDC3_FINE_COND_HIGH TRB_TDC3_FINEBINS |
Definition at line 26 of file TTrbDefines.h.
| #define TRB_TDC3_FINE_COND_LOW 0 |
Definition at line 25 of file TTrbDefines.h.
| #define TRB_TDC3_FINEBINS 0x400 |
Definition at line 18 of file TTrbDefines.h.
Referenced by TTrbProc::TTrbProc().
| #define TRB_TDC3_LdeltaT_COND_HIGH TRB_TDC3_FINEBINS |
Definition at line 28 of file TTrbDefines.h.
| #define TRB_TDC3_LdeltaT_COND_LOW (-TRB_TDC3_FINEBINS) |
Definition at line 27 of file TTrbDefines.h.
| #define TRB_TDC3_NUMBOARDS 16 |
Definition at line 6 of file TTrbDefines.h.
Referenced by TTrbEvent::AssertTDC(), and TTrbEvent::AssertTRB().
| #define TRB_TDC3_NUMTDC 1 |
Definition at line 5 of file TTrbDefines.h.
Referenced by TTrbProc::EvaluateTDCV3Data().
| #define TRB_TDC3_TdeltaT_COND_HIGH TRB_TDC3_FINEBINS |
Definition at line 30 of file TTrbDefines.h.
| #define TRB_TDC3_TdeltaT_COND_LOW (-TRB_TDC3_FINEBINS) |
Definition at line 29 of file TTrbDefines.h.
